Getting to Know Each Type of NoSQL Database

What is NoSQL?

The term NoSQL usually makes most people think of NoSQL databases or non-relational databases, but it actually means non SQL or not only SQL. In layman’s terms, it’s a database that stores data outside of relational tables. Its main advantage is that the schema is more flexible than being locked down by a table structure.

You might argue that SQL DB can ALTER TABLE, but if you have a massive amount of data or have scaled to use a distributed DB, ALTERing it once will not be fun.

Advantages of NoSQL

Scalability

Instead of scaling up by increasing the resources of a server like relational DBs (Vertical scaling), NoSQL DBs often scale up by using distributed data clusters (Horizontal scaling). Some cloud providers manage these operations behind the scenes, making it quick to scale up or down according to the incoming load.

Flexibility

NoSQL DBs often have flexible schemas that allow for faster development and easier adaptation to changes. Their flexible data models make them suitable for semi-structured and unstructured data.

High-performance

Compared to relational DBs, NoSQL DBs are designed to be optimized for specific data types, resulting in higher performance (if used for the right type of task).

Types of NoSQL DB

Let’s go through the main types of NoSQL DBs that I know and have used.

Key-value DB

Key-value DBs store data as pairs, where each pair has a unique ID, and the data value can be stored flexibly because the value doesn’t have a strict structure.

• Suitable for:
  • Session management systems
  • Storing user settings
• Examples:
  • BadgerDB
  • TiKV

In-memory key-value DB

The structure is similar to Key-value DB, but the data is stored in memory (mainly RAM). This makes reading and writing very fast, but it comes at the cost of RAM usage, and data can be lost if the system crashes. We can reduce this risk by taking snapshots and storing them periodically.

• Examples:
  • Dragonfly
  • Redis
  • Memcached

Document DB

The structure is similar to Key-value DB, except that the Key-value of Document DB is stored in document formats like JSON, XML, or YAML, grouped into collections.

• Suitable for:
  • User profiles
  • Product catalogs
  • CMS page content
• Examples:
  • MongoDB

Wide-column DB

Wide-column DBs have tables similar to relational tables, but they are better because they don’t have as strict column schemas as relational ones. This means that each row doesn’t necessarily need to have values in every column, and you can combine different parts of rows and columns with different data formats (I tried this and loved it; it’s like a hybrid of relational and non-relational).

• Suitable for:
  • Telemetry data
  • Analytics data
  • Time-series data
  • Online Messaging / Chat systems
• Examples:
  • ScyllaDB

Graph DB

This is a database that stores graph data to map relationships between data.

• Suitable for:
  • Social relationship data
  • Data used for recommendation engines (i.e., Ads, lol)
• Examples:
  • Dgraph
  • Neo4j

Time series DB

As the name suggests, this is a database that doesn’t store data by ID but by time.

• Suitable for:
  • Data from industrial systems
  • DevOps data
  • Data collected from the Internet of Things (IoT)
• Examples:
  • QuestDB
  • InfluxDB

Immutable DB

Immutable DBs store data changes used to verify data integrity, similar to Blockchain, Version Control (I admit I tried playing with this and it’s still confusing, seems a bit too specialized).

• Suitable for:
  • Accounting systems
  • Event logging systems that require change tracking
• Examples:
  • immudb
  • Dolt

Vector DB

I’ll leave this one for now. I’ll add more once I’ve had a chance to play with it.

• (Probably) suitable for:
  • Image recognition systems
  • Natural Language Processing (NLP)
  • Recommendation engines (i.e., Ads, lol)
• Examples:
  • Milvus
  • Chroma
  • Weaviate
