Did you know that column ordering in DBs is also important?

When creating tables in a database, have you ever noticed why we have to choose the data size? Let’s take a look at how important column ordering is, using PGSQL as an example.

Data Alignment in PGSQL

First, let’s look at the documentation to see what’s related to data types in the DB.

As you can see, each data type uses a different amount of space, and the actual storage size depends on the order of the columns.

From the emphasized text, we can see that good column ordering when creating a table not only affects storage but also the memory and CPU used by that table.

About Padding

After reading the Docs, if you’re still confused, let’s see how it actually works.

Start by creating two tables.

CREATE TABLE tb_fragment (col_1 smallint, col_2 bigint, col_3 int, col_4 bigint);

CREATE TABLE tb_continuous (col_1 bigint, col_2 bigint, col_3 int, col_4 smallint);

Then let’s examine how they look in storage.

SELECT a.attname, t.typname, t.typalign, t.typlen
FROM pg_class c
 JOIN pg_attribute a ON (a.attrelid = c.oid)
 JOIN pg_type t ON (t.oid = a.atttypid)
WHERE c.relname = 'tb_fragment' AND a.attnum >= 0;
 attname | typname | typalign | typlen
---------+---------+----------+--------
 col_1   | int2    | s        |      2
 col_2   | int8    | d        |      8
 col_3   | int4    | i        |      4
 col_4   | int8    | d        |      8
(4 rows)

SELECT a.attname, t.typname, t.typalign, t.typlen
FROM pg_class c
 JOIN pg_attribute a ON (a.attrelid = c.oid)
 JOIN pg_type t ON (t.oid = a.atttypid)
WHERE c.relname = 'tb_continuous' AND a.attnum >= 0;
 attname | typname | typalign | typlen
---------+---------+----------+--------
 col_1   | int8    | d        |      8
 col_2   | int8    | d        |      8
 col_3   | int4    | i        |      4
 col_4   | int2    | s        |      2
(4 rows)

As you can see:

• BIGINT uses 8 bytes
• INT uses 4 bytes
• SMALLINT uses 2 bytes

We calculate that both tables should use 22 bytes per row, but let’s look at the reality.

select pg_column_size(tb_fragment.*) - 24 as row_size from tb_fragment limit 1;
 row_size
----------
       32
(1 row)

select pg_column_size(tb_continuous.*) - 24 as row_size from tb_continuous limit 1;
 row_size
----------
       22
(1 row)

Oh, why are they not the same? Lol.

At this point, if you look at typlen, those who have read (Designing Go structs with knowledge of Computer Architecture and Data Structures) will find that it’s similar. Yes, it’s the same thing. What happened is the padding between fields.

We can use the pageinspect extension to explain what happened:

SELECT t_data FROM heap_page_items(get_raw_page('tb_fragment','main',0))gx
-[ RECORD 1 ]--------------------------------------------------------------
t_data | xff7f000000000000ffffffffffffff7fffffff7f00000000ffffffffffffff7f

SELECT t_data FROM heap_page_items(get_raw_page('tb_continuous','main',0))gx
-[ RECORD 1 ]------------------------------------------
t_data | xffffffffffffff7fffffffffffffff7fffffff7fff7f

As you can see, in the tb_fragment table, when data is retrieved, there will be zero padding until it reaches 8 bytes, and then it moves to the next column because col_1 (2 bytes) + col_2 (8 bytes) exceeds 8 bytes, causing them to be separated. This is different from tb_continuous, where col_3 (4 bytes) + col_4 (2 bytes) does not exceed 8 bytes, allowing them to be combined into the same word.

Conclusion

Planning and designing the structure by considering low-level aspects not only helps us avoid wasting storage but also improves memory and CPU usage. This is because we don’t have to waste time loading unnecessary data. However, this comes at the cost of column order readability. So, we might leave PKEYs or other indexes that make the table easier to read in the first columns, as is commonly done, without forcing an order just for performance.
